substitutions:
  name: "rgb-01"
  friendly_name: "RGB 01"
  project_name: "holman.CLXRGB60"
  project_version: "1.0"
  device_description: "RGB Light"

esphome:
  name: "${name}"
  comment: "${device_description}"
  project:
    name: "${project_name}"
    version: "${project_version}"

esp8266:
  board: esp01_1m

# OTA flashing
ota:
  - platform: esphome

wifi: # Your Wifi network details

# Enable fallback hotspot in case wifi connection fails
  ap:

# Enabling the logging component
logger:

# Enable Home Assistant API
api:

# Enable the captive portal
captive_portal:

binary_sensor:
  # Front Panel On/Off
  - platform: gpio
    pin:
      number: GPIO0
      inverted: true
      mode:
        input: true
        pullup: true
    name: "${friendly_name} Panel Button"
    id: panelButton
    on_click:
      min_length: 50ms
      max_length: 350ms
      then:
        - light.toggle: rgbLight

light:
  - platform: rgb
    name: "RGB Lights"
    red: output_component_red
    green: output_component_green
    blue: output_component_blue
    effects:
      # Use default parameters:
      - random:
      # Customize parameters
      - random:
          name: "Slow Random Effect"
          transition_length: 30s
          update_interval: 30s
      - random:
          name: "Fast Random Effect"
          transition_length: 4s
          update_interval: 5s
      - pulse:
      - pulse:
          name: "Fast Pulse"
          transition_length: 0.5s
          update_interval: 0.5s
      - pulse:
          name: "Slow Pulse"
          # transition_length: 1s      # defaults to 1s
          update_interval: 2s
      - strobe:
      - strobe:
          name: Strobe Effect With Custom Values
          colors:
            - state: true
              brightness: 100%
              red: 100%
              green: 90%
              blue: 0%
              duration: 500ms
            - state: false
              duration: 250ms
            - state: true
              brightness: 100%
              red: 0%
              green: 100%
              blue: 0%
              duration: 500ms
      - flicker:
      - flicker:
          name: Flicker Effect With Custom Values
          alpha: 95%
          intensity: 1.5%

output:
  - platform: esp8266_pwm
    id: output_component_red
    pin: GPIO13
  - platform: esp8266_pwm
    id: output_component_green
    pin: GPIO12
  - platform: esp8266_pwm
    id: output_component_blue
    pin: GPIO14

button:
  - platform: restart
    id: restart_button
    name: "${friendly_name} Restart"
    disabled_by_default: true
